| SmartFaceHandle (int _idx=-1, const PolyConnectivity *_mesh=nullptr) |
|
SmartHalfedgeHandle | halfedge () const |
| Returns one of the halfedges of the face.
|
|
PolyConnectivity::ConstFaceVertexRange | vertices () const |
| Returns a range of vertices incident to the face (PolyConnectivity::fv_range())
|
|
PolyConnectivity::ConstFaceVertexCWRange | vertices_cw () const |
| Returns a range of vertices incident to the face (PolyConnectivity::fv_cw_range())
|
|
PolyConnectivity::ConstFaceVertexCCWRange | vertices_ccw () const |
| Returns a range of vertices incident to the face (PolyConnectivity::fv_ccw_range())
|
|
PolyConnectivity::ConstFaceHalfedgeRange | halfedges () const |
| Returns a range of halfedges of the face (PolyConnectivity::fh_range())
|
|
PolyConnectivity::ConstFaceHalfedgeCWRange | halfedges_cw () const |
| Returns a range of halfedges of the face (PolyConnectivity::fh_cw_range())
|
|
PolyConnectivity::ConstFaceHalfedgeCCWRange | halfedges_ccw () const |
| Returns a range of halfedges of the face (PolyConnectivity::fh_ccw_range())
|
|
PolyConnectivity::ConstFaceEdgeRange | edges () const |
| Returns a range of edges of the face (PolyConnectivity::fv_range())
|
|
PolyConnectivity::ConstFaceEdgeCWRange | edges_cw () const |
| Returns a range of edges of the face (PolyConnectivity::fv_cw_range())
|
|
PolyConnectivity::ConstFaceEdgeCCWRange | edges_ccw () const |
| Returns a range of edges of the face (PolyConnectivity::fv_ccw_range())
|
|
PolyConnectivity::ConstFaceFaceRange | faces () const |
| Returns a range adjacent faces of the face (PolyConnectivity::ff_range())
|
|
PolyConnectivity::ConstFaceFaceCWRange | faces_cw () const |
| Returns a range adjacent faces of the face (PolyConnectivity::ff_cw_range())
|
|
PolyConnectivity::ConstFaceFaceCCWRange | faces_ccw () const |
| Returns a range adjacent faces of the face (PolyConnectivity::ff_ccw_range())
|
|
uint | valence () const |
| Returns the valence of the face.
|
|
| SmartBaseHandle (const PolyConnectivity *_mesh=nullptr) |
|
const PolyConnectivity * | mesh () const |
| Get the underlying mesh of this handle.
|
|
| FaceHandle (int _idx=-1) |
|
| BaseHandle (int _idx=-1) |
|
int | idx () const |
| Get the underlying index of this handle.
|
|
bool | is_valid () const |
| The handle is valid iff the index is not negative.
|
|
void | reset () |
| reset handle to be invalid
|
|
void | invalidate () |
| reset handle to be invalid
|
|
bool | operator== (const BaseHandle &_rhs) const |
|
bool | operator!= (const BaseHandle &_rhs) const |
|
bool | operator< (const BaseHandle &_rhs) const |
|
void | __increment () |
|
void | __decrement () |
|
void | __increment (int amount) |
|
void | __decrement (int amount) |
|
bool | feature () const |
| Returns true iff the handle is marked as feature.
|
|
bool | selected () const |
| Returns true iff the handle is marked as selected.
|
|
bool | tagged () const |
| Returns true iff the handle is marked as tagged.
|
|
bool | tagged2 () const |
| Returns true iff the handle is marked as tagged2.
|
|
bool | locked () const |
| Returns true iff the handle is marked as locked.
|
|
bool | hidden () const |
| Returns true iff the handle is marked as hidden.
|
|
bool | deleted () const |
| Returns true iff the handle is marked as deleted.
|
|
bool | is_boundary () const |
| Returns true iff the handle is boundary.
|
|
