Classes | |
| struct | Params |
Public Types | |
| typedef OpenMesh::Decimater::BaseDecimaterT< TriMesh > | BaseDecimaterType |
| typedef OpenMesh::Decimater::DecimaterT< TriMesh > | DecimaterType |
| typedef OpenMesh::Decimater::McDecimaterT< TriMesh > | McDecimaterType |
| typedef OpenMesh::Decimater::MixedDecimaterT< TriMesh > | MixedDecimaterType |
Public Slots | |
| void | decimate () |
 Public Slots inherited from OpenFlipperThread | |
| void | slotCancel (QString _jobId) |
| Cancel this job. More... | |
| void | startProcessing () |
| start processing More... | |
Public Member Functions | |
| virtual void | notify (size_t _step) |
| callback More... | |
| virtual bool | abort () const |
| Abort callback. More... | |
| void | cancel () |
| Cancel the job. More... | |
| DecimateThread (const Params &_param, QString _jobId, int _objId) | |
| BaseDecimaterType * | baseDecimater () |
| int | objectId () const |
| Public Member Functions inherited from OpenFlipperThread | |
| OpenFlipperThread (QString _jobId) | |
| void | run () |
| Main processing. More... | |
| QString | jobId () |
| get JobId get the Id of the current Job | |
| Public Member Functions inherited from OpenMesh::Decimater::Observer | |
| Observer (size_t _notificationInterval) | |
| virtual | ~Observer () |
| Destructor. | |
| size_t | get_interval () const |
| Get the interval between notification steps. | |
| void | set_interval (size_t _notificationInterval) |
| Set the interval between notification steps. | |
Private Attributes | |
| bool | abort_ |
| int | maxCollapses_ |
| Params | param_ |
| QString | jobId_ |
| BaseDecimaterType * | baseDec_ |
| int | objId_ |
Additional Inherited Members | |
| Signals inherited from OpenFlipperThread | |
| void | startProcessingInternal () |
| start processing of a function More... | |
| void | state (QString _jobId, int _state) |
| Tell core about job state. More... | |
| void | function (const QString _jobId="") |
| job function More... | |
| void | finished (QString _jobId) |
| job done More... | |
Detailed Description
Definition at line 57 of file DecimateThread.hh.
Member Function Documentation
◆ abort()
|
virtual |
Abort callback.
After each notification, this function is called by the decimater. If the function returns true, the decimater will stop at a consistent state. Otherwise it will continue.
- Returns
- abort Yes or No
Reimplemented from OpenMesh::Decimater::Observer.
Definition at line 52 of file DecimateThread.cc.
◆ cancel()
|
virtual |
Cancel the job.
Reimplement this function to correctly terminate your job. If your job is able to terminate correctly then you can reimplement this function and stop your process.
Reimplemented from OpenFlipperThread.
Definition at line 83 of file DecimateThread.cc.
◆ notify()
|
virtual |
callback
This function has to be overloaded. It will be called regularly during the decimation process and will return the current step.
- Parameters
-
_step Current step of the decimater
Implements OpenMesh::Decimater::Observer.
Definition at line 47 of file DecimateThread.cc.
The documentation for this class was generated from the following files:
- Plugin-Decimater/DecimateThread.hh
- Plugin-Decimater/DecimateThread.cc
